Informazioni sulle Mappe - Leggete Attentamente - Diritti d'autore:

- Dati Mappa

Tutti i riquadri vengono generati tramite mkgmap usando le informazioni della mappa estratti dal sito openstreetmap.org & Contributors. I dati presi da OpenStreetMap possono essere usati liberamente sotto i termini di licenza https://creativecommons.org/licenses/by-sa/2.0/ Potete usare e modificare la mappa visitando il sito openstreetmap.org. Tutti i dati della mappa vengono pubblicati tramite CCBYSA 2.0 da openstreetmap.org and Constributors.

Ringrazio Geofabrik che mi fornisce le istantanee del database che utilizzo per creare le mappe.

- other Copyrights:

See installer or copyrights.txt if extracting the .exe installer.

-- For Copyrights please see the Installer or if you unextract the installer see the file copyright.txt.

Contourlines/DEM data:

The altitude data for the contourlines is from varying sources in the following priority (if available):

  1. LIDAR data from open government data and other openly available sources - collected and converted to hgt format by Sonny This data is very very high quality and resolution - there is no better open data available according to my knowledge.
  2. ALOS World 3D30 - überall zwischen N60° und S60°
  3. SRTM 1" v3.0 - very rarely for some tiles missing in ALOS data - also only between N60° and S60°.
  4. Viewfinderpanormas 1" - then 3" - above N60° / below S60° as there is no SRTM data nor ALOS or LIDAR Data avialble.
  5. SRTM 3" v3.0 (very very rarely, 8 tiles only)



Programmi per visualizzare le Openmtbmap

Per tutte le persone della terra le mappe Openmtbmap.org vengono visualizzate su Qlandkarte_GT - QLandkarte_GT è compatibile con tutti i più grandi sistemi operativi OS (Linux, MacOSx e sì anche su Windows). In alternativa gli utenti Linux possono installare Mapsource 6.13.6 in WINE.

For Linux/Unix users there is also a script to unpack the maps, and automatically create a gmapsupp: https://github.com/btittelbach/openmtbmap_openvelomap_linux After unpacking you find instructions for Qlandkarte / Linux use in a .txt file (informations... .txt).

Mapsource - Attualmente consiglio di usare la versione 6.16.3 o superiore. Le versioni di Mapsource dalla 6.14 alla 6.15.6 sono un completo disastro, se le state usate, siete pregati di aggiornale. Da notare che le versioni di Mapsource precedenti la 6.16.1 non visualizzano tutte le strade e sentieri quindi non sono molto utilizzabili.

Gli utenti Mac OSx possono usare Qlandkarte GT o convertire le mappe e usare Basecamp 3 o Roadtrip: convertire mappe per mac-os-x-roadtrip/

ATTENTION - MapInstall 4.2.0 is partly broken. It will come as Update with Basecamp 4.7.0 but can also update via other Garmin Tools. Best downgrade - see also here: Do Not Update to Basecamp v4.7.0

Problemi - Aiuto - Guide

Una guida per Principianti può essere trovata qui: come inziare con openmtbmaps

Installare Mapsource: tutorials/installare-mapsource/

Installare le Openmtbmap su Mapsource: tutorials/install/ spiegazione su come usare install*.bat. Per un uso più generico installare tramite il file eseguibile .exe.

In Alternativa: usare create_mapsource_installationfiles.bat per creare nuovi file di installazione.

Alternativa: Installare le mappe tramite gmaptool: tutorials/install/gmaptool-install-maps/

Alternativa sconsigliata: Installare le mappe con Mapsettoolkit: tutorials/install/installation-with-mapsettoolkit/

Mandare le mappe al GPS tramite Mapsource: tutorials/send-maps-to-your-gps/mapsource/

Io consiglio sempre di mandare le mappe ad una memoria esterna e non alla memoria interna del GPS. (In questo modo se qualcosa va male, o le mappe si danneggiano, si corre meno il pericolo di danneggiare il proprio GPS).

Alternativa: Usare create_gmapsupp.img.bat e mettere il nuovo file creato gmapsupp.img dentro la cartella /garmin del proprio GPS. La ricerca degli indirizzi non viene inclusa in questo modo.

Mandare le mappe al GPS con mkgmap (per utenti Unix): tutorials/send-maps-to-your-gps/mkgmap/

Errori in Mapsource / debug Mapsource: C'è un problema con il registro di sistema per MapSource. Siete pregati di reinstallare Mapsource e riavviarlo Potete risolvere con Mapsource Fix O con Mapset Toolkit

Si prega inoltre di leggere le FAQ

Change Layout and Contrast of the maps

On installation you can choose the layout of the maps. Traditional layout is for Qlandkarte GT, Mapsource and Basecamp and offers a good layout and design for big screens. On the GPS thin, classic and wide or easy or hiking offer high contrast for best orientation while riding your bike or hiking.

In order to change the layout - simply run openmtbmap_country_change_layout.exe (this is also linked in your Start --> Programs Folder for each map). This also enables you to quickly change the layout before sending maps to your GPS device, and then quickly change it back for better planning on your desktop.

You can adapt the .TYP-files, which are responsible for the layout - and therefore the map colours, to your liking by using http://www.maptk.dnsalias.com/. Do not use http://ati.land.cz/gps/typdecomp/editor.cgi because it is not fully compatible and may corrupt the .TYP-file.

Problemi conosciuti

- Se l'invio delle mappe al GPS tramite Mapsource non va a buon fine, lanciare unregister_or_reregister_address_search.bat per annullare la registrazione dell'indice di ricerca degli indirizzi da Mapsource.

- La ricerca indirizzi è ottimizzata, in questo momento (13.2.2010), più o meno al 90% rispetto a come si potrebbe lavorare con i dati contenuti in OSM. La maggior parte dei problemi è dovuta all'inconsistenza della struttura degli indirizzi nei dati OSM.

- In Generale: Autorouting sulle lunghe distanze sul GPS funziona tramite le vie . Si risolve con WinGDB: pianificare-percorsi-in-modo-efficiente

- L'Autorouting necessita di attributi come tracktype, bicycle routes, mtb:scale, sac_scale, mtb routes e altri per funzionare bene. Quindi prestate attenzione e inserite questi dettagli in OSM. (non tutti sono necessari, ma sono abbastanza per me per cercare di capire quando una strada è ciclabile per le bici o per le mtb o no).

- Le strade non collegate e le strade sovrapposto senza nodi di collegamento, sono i problemi principali e il problema che è alla base dei dati cartografici - controllate qui: http://keepright.ipax.at/report_map.php

Selezionate/Abilitate solo: "quasi incrocio" , "Intersezione senza congiunzione" così come "overlapping ways". Questo vi aiuterà a identificare velocemente gli errori. Potrete così seguire il collegamento a Potlatch (è integrato anche JOSM per gli utenti JOSM) e correggere velocemente il problema!

Fate attenzione a non connettere strade che non siano realmente connesse in realtà (p.e. una strada che ne incrocia un altra su un ponte, in questo caso la soluzione giusta è proprio nessun nodi di congiunzione) - Se usate Windows 2000 potreste aver bisogno di installare l'aggiornamento : Reg cmd at Microsoft. I comandi batches non erano compatibili nelle vecchie versioni di Windows.

- Da notare che a volte manca il mare. Questo non è un problema, ma attualmente non è possibile fare diversamente. E' un problema comune nei dati OSM.



Velomap and Openmtbmap of the same Country -- Problems

If you install an openmtbmap and a VeloMap of the same country with both times integrated contourlines, you should only send the contourlines once (meaning with either Openmtmbap or Velomap of the country).. Else you GPS might not show the maps, or worse not even start until maps are deleted. There are several possibilities.

a) Install both maps without contourlines and contourlines separately (install separate contourlines only map option in installer). You have not trouble.

b) Use the create_gmapsupp... .bat batchfiles and for one map select no contourlines.

c) be careful here: Select the map as usual in Basecamp/Mapsource or Qlandkarte GT, then go to the list of the selected tiles ready to be sent to the GPS, scroll down to the bottom, and unselect the contourlines only tiles from the list.

Notifiche per l'Aggiornamento Mappe

Se volete essere avvisati tramite email degli aggiornamenti alla mappa andate nell'home page ed inserite la vostra email nel campo di sottoscrizione nella barra a sinistra. Riceverete solo un email quando ci saranno modifiche sostanziali alla mappa più che semplici aggiornamenti dei dati. Gli aggiornamenti alla mappa vengono fatti normalmente tutti i giovedì notte/venerdì mattina. Potete dare un'occhiata al server per vedere la data di caricamento della mappa.

Per aggiornare le mappe, lanciate semplicemente il nuovo file .exe scaricato.

Mappe sovrapposte nelle Zone di Confine

Mentre è possibile unire mappe di nazioni differenti, l'autorouting oltre i confini è un pò traballante, e avrete una mappa soprapposta alle altre con sfondo bianco. Fino a quando mkgmap non potrà creare cannot create mappe con forme variabili (attualmente solo rettangoli), il problema non sarà risolvibile. Tuttavia c'è la possibilità di scaricare la mappa dell'Europa, che viene aggiornata ogni 4-6 settimane. Potete scaricare la Mappa Europea qui (è necessario fare una donazione): https://openmtbmap.org/support/europe-map/

Compatibility

In general just download the Maps from the first "OpenMTBMap" tab - they are in Unicode if useful. Some maps by default are in Unicode. You can identify them by (Unicode) note behind the name - alll countries/maps not listed on the "Non Unicode" tab are anyhow Non Unicode. If you get the message - "cannot authenticate maps", and you have you have one of the following devices:

  • All Garmin devices presented 2016 or newer
  • Edge 1000
  • Epix
  • Etrex 20x / 30x (not "etrex 30")
  • Etrex Touch 25/35
  • GPS Maps 64 series
  • Montana 610, 680 (not 600 / 650)
  • Oregon 700,750
  • Some recent Nuvi devices - as well as some super old devices that do not support Unicode. (E.g. Garmin Vista C, GPS Maps 60 C)

you will need to download the "non unicode" version of the map instead. So get the map from the "non unicode openmtbmap" tab instead. Only maps of regions where several different scripts are used - are in unicode. If Latin is the predominant script - then of course no unicode map is offered. If your device can display Unicode maps - then of course get the standard version - meaning Unicode.

Commenti

Siete pregato di commentare queste mappe o meglio ancora dicendolo ad altre persone (forums, blog about it, twitter, etc…) Nel caso in cui le mappe rovinino Mapsource o non funzionino -siete pregati di scrivere esattamente quali download non funzionano e l'orario di scaricamento così come il sistema operativo usato e la versione di Mapsource. Si prega di notare che cancellerò senza nessuna notifica nel caso in cui sia già spiegato qui https://openmtbmap.org/download/#problems-help-tutorials o nelle FAQ

Mappe

ultimo aggiornamento mappe: per favore guardate i post recenti - di solito almeno ogni 7 giorni con aggiornamento Giovedì/Venerdì

Potete scompattare il file .exe con 7-zip , ( Gli utenti Linux possono usare p7zip-full --> vedere qui per maggiori dettagli y https://github.com/btittelbach/openmtbmap_openvelomap_linux), After unpacking you find instructions for Qlandkarte / Linux use in a .txt file (informations... .txt).

Le Contourlines(Curve di livello) sono disponibili come download separati - si prega di scrollare giù: contourlines

To see the last update time - just look at the MD5 file.





Standard - Local Language Maps

Legenda Mappa

Continenti mappe downloads:

Europa mappe downloads:

L’Europa come unica mappa può essere trovata qui: Europa (aggiornato circa ogni 6 settimane)

Paesi Federali Tedeschi:

France – Francia DOM-TOM (premium maps):

Africa map downloads – (contourlines separate download except Botswana,Canary Islands, Cape-Verde, Comores, Kenya, Mauritius, Saint-Helena-Ascension and Tristan-da-Cunha, Seychelles, Sudan, Tunisia):

Asia Map Downloads – (contourlines separate download except Bhutan, Bangladesh, Jordan, Lebanon, Myanmar, South-Korea, Sri-Lanka, Syria):



Australia-Oceania Premium map downloads:

North America Premium mappe downloads:

South America Premium Mappe Downloads:

Premium English Language Maps - ONLY for Countries not using Latin and Central/South America

Continenti mappe downloads:

Europa mappe downloads:

L’Europa come unica mappa può essere trovata qui: Europa (aggiornato circa ogni 6 settimane)

Africa map downloads – (contourlines separate download except Botswana,Canary Islands, Cape-Verde, Comores, Kenya, Mauritius, Saint-Helena-Ascension and Tristan-da-Cunha, Seychelles, Sudan, Tunisia):

Asia Map Downloads – (contourlines separate download except Bhutan, Bangladesh, Jordan, Lebanon, Myanmar, South-Korea, Sri-Lanka, Syria):

Contourlines Premium Downloads

Most countries, especially the popular ones, have the contourlines already integrated. However for several countries the contourlines are rather large (rule of thumb if contourlines have more data than the maps) and I integrate them, but you need to download them separately (once). The installer will ask for the contourlines file as soon as you activate the checkbox to integrate the contourlines in the installer. You do not need to extract the contourlines - this will be done by the installer (and is only needed once. On updates you don't need to redo it).

In general it is fine to only update the map, as I try to change the contourlines as seldom as possible.

Continents





Africa

Asia:

Australia-Oceania:

Europa

North America

South America

Openmtbmap (and VeloMap) maps Premium Download in Mac OSx format (gmap)

I have decided to make available all openmtbmaps and velomaps available also in gmap format. Please look here: https://openmtbmap.org/es/download/macosx/

For VeloMap downloads please go here: https://openmtbmap.org/it/download/velomap/

(note if you are not a OpenMTBMap member - please go directly to www.velomap.org/

Non Unicode Premium Maps - Only offered for Non Latin Using Countries/Regions

In general just download the Maps from the first "OpenMTBMap" tab - they are in Unicode if useful. Some maps by default are in Unicode. You can identify them by (Unicode) note behind the name - alll countries/maps not listed on the "Non Unicode" tab are anyhow Non Unicode. If you get the message - "cannot authenticate maps", and you have you have one of the following devices:

  • All Garmin devices presented 2016 or newer
  • Edge 1000
  • Epix
  • Etrex 20x / 30x (not "etrex 30")
  • Etrex Touch 25/35
  • GPS Maps 64 series
  • Montana 610, 680 (not 600 / 650)
  • Oregon 700,750
  • Some recent Nuvi devices - as well as some super old devices that do not support Unicode. (E.g. Garmin Vista C, GPS Maps 60 C)

you will need to download the "non unicode" version of the map instead. So get the map from the "non unicode openmtbmap" tab instead. Only maps of regions where several different scripts are used - are in unicode. If Latin is the predominant script - then of course no unicode map is offered. If your device can display Unicode maps - then of course get the standard version - meaning Unicode.

Note1: if you install the non Unicode version of a map - you will overwrite the Unicode map. You can only have either or installed.

Note2: The contourlines are identical for openmtbmap/velomap and unicode or non unicode. You only need to download them once. On updates it's enough to re-download and reinstall the map installer.

Note3:Here only those countries are listed - where the standard download is Unicode. If you don't find a country here - look at the standard downloads.

Note4: Sri-Lanka, Nepal and Cambodia are in latin1  - so the local language maps are not very useful. There is no ANSI Codepage available (besides Unicode) that would support the script/garmin units. Israel-Palestine map is in hebrew (so the Palestine area is not useful). Afghanistan codepage is for Dari - Pashto is not supported outside of Unicode.
